ABB ACS880-104

Parameters 227
15.86 AO2 actual value (Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.86 AO2 actual value.
-
15.87 AO2 source (Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.87 AO2 source.
Zero
15.88 AO2 force data (Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.88 AO2 force data.
0.000 mA
15.89 AO2 filter time (Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.89 AO2 filter time.
0.100 s
15.90 AO2 source min (Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.90 AO2 source min.
0.0
15.91 AO2 source max (Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.91 AO2 source max.
100.0
15.92 AO2 out at AO2 src
min
(Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.92 AO2 out at AO2 src min.
0.000 mA
15.93 AO2 out at AO2 src
max
(Visible when 15.01 Module 2 type = FAIO-01)
See parameter 14.93 AO2 out at AO2 src max.
10.000 mA
16
16 I/O extension
module 3
Configuration of I/O extension module 3.
See also section Programmable I/O extensions (page 65).
Note: The contents of the parameter group vary according to
the selected I/O extension module type.
16.01 Module 3 type See parameter 14.01 Module 1 type. None
16.02 Module 3 location See parameter 14.02 Module 1 location. Slot 1
16.03 Module 3 status See parameter 14.03 Module 1 status. No option
16.05 DI status (Visible when 16.01 Module 3 type = FDIO-01)
See parameter 14.05 DI status.
-
16.05 DIO status (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.05 DIO status.
-
16.06 DI delayed status (Visible when 16.01 Module 3 type = FDIO-01)
See parameter 14.06 DI delayed status.
-
16.06 DIO delayed status (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.06 DIO delayed status.
-
16.08 DI filter time (Visible when 16.01 Module 3 type = FDIO-01)
See parameter 14.08 DI filter time.
10.0 ms
16.08 DIO filter time (Visible when 16.01 Module 3 type =
FIO-01 or FIO-11)
See parameter 14.08 DIO filter time.
10.0 ms
16.09 DIO1 function (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.09 DIO1 function.
Input
16.11 DIO1 output source (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.11 DIO1 output source.
Not
energized
16.12 DI1 ON delay (Visible when 16.01 Module 3 type = FDIO-01)
See parameter 14.12 DI1 ON delay.
0.00 s
16.12 DIO1 ON delay (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.12 DIO1 ON delay.
0.00 s
16.13 DI1 OFF delay (Visible when 16.01 Module 3 type = FDIO-01)
See parameter 14.13 DI1 OFF delay.
0.00 s
No. Name/Value Description Def/FbEq16
