Additional parameter data 519
15.90 AO2 source min Real -32768.0 … 32767.0 - 10 = 1
15.91 AO2 source max Real -32768.0 … 32767.0 - 10 = 1
15.92 AO2 out at AO2 src min Real 0.000 … 22.000 mA 1000 = 1 mA
15.93 AO2 out at AO2 src max Real 0.000 … 22.000 mA 1000 = 1 mA
16 I/O extension module 3
16.01 Module 3 type List 0…4 - 1 = 1
16.02 Module 3 location Real 1…254 - 1 = 1
16.03 Module 3 status List 0…2 - 1 = 1
DIx (16.01 Module 3 type = FDIO-01)
16.05 DI status PB 00000000h…FFFFFFFFh - 1 = 1
16.06 DI delayed status PB 00000000h…FFFFFFFFh - 1 = 1
16.08 DI filter time Real 0.8 … 100.0 ms 10 = 1 ms
16.12 DI1 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.13 DI1 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
16.17 DI2 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.18 DI2 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
16.22 DI3 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.23 DI3 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
Common parameters for DIOx (16.01 Module 3 type = FIO-01 or FIO-11)
16.05 DIO status PB 00000000h…FFFFFFFFh - 1 = 1
16.06 DIO delayed status PB 00000000h…FFFFFFFFh - 1 = 1
DIO1/DIO2 (16.01 Module 3 type = FIO-01 or FIO-11)
16.08 DIO filter time Real 0.8 … 100.0 ms 10 = 1 ms
16.09 DIO1 function List 0…1 - 1 = 1
16.11 DIO1 output source Binary
src
--1 = 1
16.12 DIO1 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.13 DIO1 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
16.14 DIO2 function List 0…1 - 1 = 1
16.16 DIO2 output source Binary
src
--1 = 1
16.17 DIO2 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.18 DIO2 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
DIO3/DIO4 (16.01 Module 3 type
= FIO-01)
16.19 DIO3 function List 0…1 - 1 = 1
16.21 DIO3 output source Binary
src
--1 = 1
16.22 DIO3 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.23 DIO3 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
16.24 DIO4 function List 0…1 - 1 = 1
16.26 DIO4 output source Binary
src
--1 = 1
No. Name Type Range Unit FbEq32
