384 Parameters
Refresh Refreshing. 1
54.28 FBA B par table ver Displays the parameter table revision of the fieldbus adapter
module mapping file (stored in the memory of the drive).
In format axyz, where ax = major table revision number; yz =
minor table revision number.
This parameter is read-only.
-
Parameter table revision of adapter module. -
54.29 FBA B drive type
code
Displays the drive type code in the fieldbus adapter module
mapping file (stored in the memory of the drive).
This parameter is read-only.
-
0…65535 Drive type code stored in the mapping file. 1 = 1
54.30 FBA B mapping file
ver
Displays the fieldbus adapter module mapping file revision
stored in the memory of the drive in decimal format.
This parameter is read-only.
-
0…65535 Mapping file revision. 1 = 1
54.31 D2FBA B comm
status
Displays the status of the fieldbus adapter module
communication.
-
Not configured Adapter is not configured. 0
Initializing Adapter is initializing. 1
Time out A timeout has occurred in the communication between the
adapter and the drive.
2
Configuration error Adapter configuration error: mapping file not found in the file
system of the drive, or mapping file upload has failed more
than three times.
3
Off-line Fieldbus communication is off-line. 4
On-line Fieldbus communication is on-line, or fieldbus adapter has
been configured not to detect a communication break. For
more information, see the documentation of the fieldbus
adapter.
5
Reset Adapter is performing a hardware reset. 6
54.32 FBA B comm SW
ver
Displays the patch and build versions of the adapter module
firmware in format xxyy, where xx = patch version number, yy
= build version number.
Example: C802 = 200.02 (patch version 200, build version 2).
Patch and build versions of adapter module firmware. -
54.33 FBA B appl SW ver Displays the major and minor versions of the adapter module
firmware in format xyy, where x = major revision number, yy =
minor revision number.
Example: 300 = 3.00 (major version 3, minor version 00).
Major and minor versions of adapter module firmware. -
55
55 FBA B data in
Selection of data to be transferred from drive to fieldbus
controller through fieldbus adapter B.
55.01 FBA B data in1 Parameters 55.01…55.12 select data to be transferred from
the drive to the fieldbus controller through fieldbus adapter B.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
No. Name/Value Description Def/FbEq16
