ABB ACS880-104

152 Parameters
Parameter listing
No. Name/Value Description Def/FbEq16
01
01 Actual values
Basic signals for monitoring the drive.
All parameters in this group are read-only unless otherwise
noted.
01.01 Motor speed used Measured or estimated motor speed depending on which
type of feedback is used (see parameter 90.41 Motor
feedback selection). A filter time constant for this signal can
be defined by parameter 46.11 Filter time motor speed.
-
-30000.00 …
30000.00 rpm
Measured or estimated motor speed. See par.
46.01
01.02 Motor speed
estimated
Estimated motor speed in rpm. A filter time constant for this
signal can be defined by parameter 46.11 Filter time motor
speed.
-
-30000.00 …
30000.00 rpm
Estimated motor speed. See par.
46.01
01.03 Motor speed % Shows the value of 01.01 Motor speed used in percent of the
synchronous speed of the motor.
10 = 1%
-1000.00 …
1000.00%
Measured or estimated motor speed. See par.
46.01
01.04 Encoder 1 speed
filtered
Speed of encoder 1 in rpm. A filter time constant for this
signal can be defined by parameter 46.11 Filter time motor
speed.
-
-30000.00 …
30000.00 rpm
Encoder 1 speed. See par.
46.01
01.05 Encoder 2 speed
filtered
Speed of encoder 2 in rpm. A filter time constant for this
signal can be defined by parameter 46.11 Filter time motor
speed.
-
-30000.00 …
30000.00 rpm
Encoder 2 speed. See par.
46.01
01.06 Output frequency Estimated drive output frequency in Hz. A filter time constant
for this signal can be defined by parameter 46.12 Filter time
output frequency.
-
-500.00 … 500.00
Hz
Estimated output frequency. See par.
46.02
01.07 Motor current Measured (absolute) motor current in A. -
0.00 … 30000.00 A Motor current. See par.
46.05
01.08 Motor current % of
motor nom
Motor current (drive output current) in percent of the nominal
motor current.
-
0.0 … 1000.0% Motor current. 1 = 1%
01.10 Motor torque Motor torque in percent of the nominal motor torque. See also
parameter 01.30 Nominal torque scale
.
A filter time constant for this signal can be defined by
parameter 46.13 Filter time motor torque.
-
-1600.0 … 1600.0% Motor torque. See par.
46.03
01.11 DC voltage Measured DC link voltage. -
0.00 … 2000.00 V DC link voltage. 10 = 1 V
