Parameters 153
01.13 Output voltage Calculated motor voltage in V AC. -
0…2000 V Motor voltage. 1 = 1 V
01.14 Output power Drive output power. The unit is selected by parameter 96.16
Unit selection. A filter time constant for this signal can be
defined by parameter 46.14 Filter time power out.
-
-32768.00 …
32767.00 kW or hp
Output power. 1 = 1 unit
01.15 Output power % of
motor nom
Shows the value of 01.14 Output power in percent of the
nominal power of the motor.
-
-300.00 … 300.00% Output power. 10 = 1%
01.17 Motor shaft power Estimated mechanical power at motor shaft. The unit is
selected by parameter 96.16 Unit selection. A filter time
constant for this signal can be defined by parameter 46.14
Filter time power out.
-
-32768.00 …
32767.00 kW or hp
Motor shaft power. 1 = 1 unit
01.18 Inverter GWh
motoring
Amount of energy that has passed through the drive (towards
the motor) in full gigawatt-hours. The minimum value is zero.
-
0…32767 GWh Motoring energy in GWh. 1 = 1 GWh
01.19 Inverter MWh
motoring
Amount of energy that has passed through the drive (towards
the motor) in full megawatt-hours. Whenever the counter rolls
over, 01.18 Inverter GWh motoring is incremented.The
minimum value is zero.
-
0…999 MWh Motoring energy in MWh. 1 = 1 MWh
01.20 Inverter kWh
motoring
Amount of energy that has passed through the drive (towards
the motor) in full kilowatt-hours. Whenever the counter rolls
over, 01.19 Inverter MWh motoring is incremented.The
minimum value is zero.
-
0…999 kWh Motoring energy in kWh. 10 = 1 kWh
01.21 U-phase current Measured U-phase current. -
-30000.00 …
30000.00 A
U-phase current. See par.
46.05
01.22 V-phase current Measured V-phase current. -
-30000.00 …
30000.00 A
V-phase current. See par.
46.05
01.23 W-phase current Measured W-phase current. -
-30000.00 …
30000.00 A
W-phase current. See par.
46.05
01.24 Flux actual % Used flux reference in percent of nominal flux of motor. -
0…200% Flux reference. 1 = 1%
01.29 Speed change rate Rate of actual speed change. Positive values indicate
acceleration, negative values indicate deceleration.
See also parameters 31.32
Emergency ramp supervision,
31.33 Emergency ramp supervision delay, 31.37 Ramp stop
supervision and 31.38 Ramp stop supervision delay.
-
-15000 … 15000
rpm/s
Rate of speed change. 1 = 1 rpm/s
No. Name/Value Description Def/FbEq16
