Parameters 365
46.05 Current scaling Defines the 16-bit scaling of current parameters. The value of
this parameter corresponds to 10000 in fieldbus,
master/follower etc. communication.
10000 A
0…30000 A Current corresponding to 10000 on fieldbus. 1 = 1 A
46.06 Speed ref zero
scaling
Defines a speed corresponding to a zero reference received
from fieldbus (either the embedded fieldbus interface, or
interface FBA A or FBA B). For example, with a setting of
500, the fieldbus reference range of 0…20000 would
correspond to a speed of 500…[46.01] rpm.
Note: This parameter is effective only with the ABB Drives
communication profile.
0.00 rpm
0.00 … 30000.00
rpm
Speed corresponding to minimum fieldbus reference. 1 = 1 rpm
46.07 Frequency ref zero
scaling
Defines a frequency corresponding to a zero reference
received from fieldbus (either the embedded fieldbus
interface, or interface FBA A or FBA B). For example, with a
setting of 30, the fieldbus reference range of 0…20000 would
correspond to a speed of 30…[46.02] Hz.
Note: This parameter is effective only with the ABB Drives
communication profile.
0.00 Hz
0.00 … 1000.00 Hz Frequency corresponding to minimum fieldbus reference. 10 = 1 Hz
46.11 Filter time motor
speed
Defines a filter time for signals 01.01 Motor speed used,
01.02 Motor speed estimated, 01.04 Encoder 1 speed filtered
and 01.05 Encoder 2 speed filtered.
500 ms
0…20000 ms Motor speed signal filter time. 1 = 1 ms
46.12 Filter time output
frequency
Defines a filter time for signal 01.06 Output frequency. 500 ms
0…20000 ms Output frequency signal filter time. 1 = 1 ms
46.13 Filter time motor
torque
Defines a filter time for signal 01.10 Motor torque. 100 ms
0…20000 ms Motor torque signal filter time. 1 = 1 ms
46.14 Filter time power
out
Defines a filter time for signal 01.14 Output power. 100 ms
0…20000 ms Output power signal filter time. 1 = 1 ms
No. Name/Value Description Def/FbEq16
