ABB ACS880-104

460 Parameters
Other [bit] Source selection (see Terms and abbreviations on page 148). -
90.68 Disable pos counter
initialization
Selects a source that prevents the initialization of the position
counter.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
90.69 Reset pos counter
init ready
Selects a source that enables a new initialization of the
position counter, ie. resets bit 4 of 90.35 Pos counter status.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02
DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
91
91 Encoder module
settings
Configuration of encoder interface modules.
91.01 FEN DI status Displays the status of the digital inputs of FEN-xx encoder
interface modules.
This parameter is read-only.
-
0000 0000b …
0011 0011b
Status word of digital inputs on FEN-xx modules. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Information
0 DI1 /module 1 DI1 of interface module 1 (see parameters 91.11 and 91.12)
1 DI2 /module 1 DI2 of interface module 1 (see parameters 91.11 and 91.12)
2…3 Reserved
4 DI1 /module 2 DI1 of interface module 2 (see parameters 91.13 and 91.14)
5 DI2 /module 2 DI2 of interface module 2 (see parameters 91.13 and 91.14)
6…15 Reserved
