Parameters 459
90.63 Feed constant
numerator
Parameters 90.63 and 90.64 define the feed constant for the
position calculation:
The feed constant converts rotational motion into translatory
motion. The feed constant is the distance the load moves
during one turn of the motor shaft.
The translatory load position is shown by parameter 90.05
Load position scaled. Note that the load position is only
updated after new position input data is received.
1
-2147483648 …
2147483647
Feed constant numerator. -
90.64 Feed constant
denominator
See parameter 90.63 Feed constant numerator.1
-2147483648 …
2147483647
Feed constant denominator. -
90.65 Pos counter init
value
Defines an initial position (or distance) for the position counter
(as a decimal number) when parameter 90.66 Pos counter
init value source is set to Pos counter init value.
The number of decimal places is defined by parameter 90.38
Pos counter decimals.
0.000
-2147483.648 …
2147483.647
Initial value for position counter. -
90.66 Pos counter init
value source
Selects the source of the initial position value. When the
source selected by 90.67 Pos counter init cmd source
activates, the value selected in this parameter is assumed to
be the position of the load (in decimal format).
Pos counter
init value
Zero 0. 0
Pos counter init
value
Parameter 90.65 Pos counter init value.1
Other Source selection (see Terms and abbreviations on page 148). -
90.67 Pos counter init
cmd source
Selects a digital source (for example, a limit switch connected
to a digital input) that initializes the position counter. When the
digital source activates, the value selected by 90.66 Pos
counter init value source is assumed to be the position of the
load.
Note: Position counter initialization can be prevented by
parameter 90.68 Disable pos counter initialization.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status
, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
No. Name/Value Description Def/FbEq16
90.63 Feed constant numerator
90.64 Feed constant denominator
