Additional parameter data 543
53 FBA A data out
53.01 FBA A data out1 List --1 = 1
…… ………
53.12 FBA A data out12 List --1 = 1
54 FBA B settings
54.01 FBA B type
54.02 FBA B Par2 UINT16 0…65535 -
…… ………
54.26 FBA B Par26 UINT16 0…65535 -
54.27 FBA B par refresh List 0…1 -
54.28 FBA B par table ver UINT16 0…65535 -
54.29 FBA B drive type code UINT16 0…65535 -
54.30 FBA B mapping file ver UINT16 0…65535 -
54.31 D2FBA B comm status List 0…6 -
54.32 FBA B comm SW ver UINT16 0…65535 -
54.33 FBA B appl SW ver UINT16 0…65535 -
55 FBA B data in
55.01 FBA B data in1 List --1 = 1
…… ………
55.12 FBA B data in12 List --1 = 1
56 FBA B data out
56.01 FBA B data out1 List --1 = 1
…… ………
56.12 FBA B data out12 List --1 = 1
58 Embedded fieldbus
58.01 Protocol enable List 0…1 - 1 = 1
58.02 Protocol ID Real 0000h…FFFFh - 1 = 1
58.03 Node address Real 0…255 - 1 = 1
58.04 Baud rate List 2…7 - 1 = 1
58.05 Parity List 0…3 - 1 = 1
58.06 Communication control List 0…2 - 1 = 1
58.07 Communication diagnostics PB 0000h…FFFFh - 1 = 1
58.08 Received packets Real 0…4294967295 - 1 = 1
58.09 Transmitted packets Real 0…4294967295 - 1 = 1
58.10 All packets Real 0…4294967295 - 1 = 1
58.11 UART errors Real 0…4294967295 - 1 = 1
58.12 CRC errors Real 0…4294967295 - 1 = 1
58.14 Communication loss action List 0…5 - 1 = 1
58.15 Communication loss mode List 1…2 - 1 = 1
58.16 Communication loss time Real 0.0 … 6000.0 s 10 = 1 s
58.17 Transmit delay Real 0…65535 ms 1 = 1 ms
No. Name Type Range Unit FbEq32
