ABB ACS880-104

Parameters 149
Summary of parameter groups
Group Contents Page
01 Actual values Basic signals for monitoring the drive. 152
03 Input references Values of references received from various sources. 156
04 Warnings and faults Information on warnings and faults that occurred last. 157
05 Diagnostics Various run-time-type counters and measurements related to drive
maintenance.
164
06 Control and status words Drive control and status words. 165
07 System info Information on drive hardware, firmware and application program. 180
09 ESP signals ESP signals to monitor the pump. 183
10 Standard DI, RO Configuration of digital inputs and relay outputs. 184
11 Standard DIO, FI, FO Configuration of digital input/outputs and frequency inputs/outputs. 191
12 Standard AI Configuration of standard analog inputs. 196
13 Standard AO Configuration of standard analog outputs. 200
14 I/O extension module 1 Configuration of I/O extension module 1. 204
15 I/O extension module 2 Configuration of I/O extension module 2. 223
16 I/O extension module 3 Configuration of I/O extension module 3. 227
19 Operation mode Selection of local and external control location sources and
operating modes.
231
20 Start/stop/direction Start/stop/direction and run/start/jog enable signal source
selection; positive/negative reference enable signal source
selection.
233
21 Start/stop mode Start and stop modes; emergency stop mode and signal source
selection; DC magnetization settings; autophasing mode
selection.
242
22 Speed reference selection Speed reference selection; motor potentiometer settings. 249
23 Speed reference ramp Speed reference ramp settings (programming of the acceleration
and deceleration rates for the drive).
257
24 Speed reference
conditioning
Speed error calculation; speed error window control configuration;
speed error step.
263
25 Speed control Speed controller settings. 268
26 Torque reference chain Settings for the torque reference chain. 279
28 Frequency reference chain Settings for the frequency reference chain. 285
30 Limits Drive operation limits. 294
31 Fault functions Configuration of external events; selection of behavior of the drive
upon fault situations.
302
32 Supervision Configuration of signal supervision functions 1…3. 312
33 Generic timer & counter Configuration of maintenance timers/counters. 315
35 Motor thermal protection Motor thermal protection settings such as temperature
measurement configuration, load curve definition and motor fan
control configuration.
323
36 Load analyzer Peak value and amplitude logger settings. 334
37 User load curve Settings for user load curve.
338
40 Process PID set 1 Parameter values for process PID control. 341
41 Process PID set 2 A second set of parameter values for process PID control. 353
