ABB ACS880-104

520 Additional parameter data
16.27 DIO4 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.28 DIO4 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
RO1/RO2 (16.01 Module 3 type = FIO-01 or FDIO-01)
16.31 RO status PB 0000h…FFFFh - 1 = 1
16.34 RO1 source Binary
src
--1 = 1
16.35 RO1 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.36 RO1 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
16.37 RO2 source Binary
src
--1 = 1
16.38 RO2 ON delay Real 0.00 … 3000.00 s 100 = 1 s
16.39 RO2 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
Common parameters for AIx (16.01 Module 3 type = FIO-11 or FA IO-01 )
16.19 AI supervision function List 0…4 - 1 = 1
16.20 AI supervision selection PB 0000h…FFFFh - 1 = 1
16.21 AI tune List 0…6 (FIO-11)
0…4 (FAIO-01 )
-1 = 1
16.22 AI force selection PB 00000000h…FFFFFFFFh - 1 = 1
AI1/AI2 (16.01 Module 3 type = FIO-11 or FAIO-01)
16.26 AI1 actual value Real -22.000 … 22.000 mA or V 1000 = 1 unit
16.27 AI1 scaled value Real -32768.000 … 32767.000 - 1000 = 1
16.28 AI1 force data Real -22.000 … 22.000 mA or V 1000 = 1 unit
16.29 AI1 HW switch position List --1 = 1
16.30 AI1 unit selection List --1 = 1
16.31 AI1 filter gain List 0…7 - 1 = 1
16.32 AI1 filter time Real 0.000 … 30.000 s 1000 = 1 s
16.33 AI1 min Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
16.34 AI1 max Real
-22.000 … 22.000 mA or V 1000 = 1 mA
or V
16.35 AI1 scaled at AI1 min Real -32768.000 … 32767.000 - 1000 = 1
16.36 AI1 scaled at AI1 max Real -32768.000 … 32767.000 - 1000 = 1
16.41 AI2 actual value Real -22.000 … 22.000 mA or V 1000 = 1 unit
16.42 AI2 scaled value Real -32768.000 … 32767.000 - 1000 = 1
16.43 AI2 force data Real -22.000 … 22.000 mA or V 1000 = 1 unit
16.44 AI2 HW switch position List --1 = 1
16.45 AI2 unit selection List --1 = 1
16.46 AI2 filter gain List 0…7 - 1 = 1
16.47 AI2 filter time Real 0.000 … 30.000 s 1000 = 1 s
16.48 AI2 min Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
16.49 AI2 max Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
No. Name Type Range Unit FbEq32
