ABB ACS880-104

Additional parameter data 521
16.50 AI2 scaled at AI2 min Real -32768.000 … 32767.000 - 1000 = 1
16.51 AI2 scaled at AI2 max Real -32768.000 … 32767.000 - 1000 = 1
AI3 (16.01 Module 3 type = FIO-11)
16.56 AI3 actual value Real -22.000 … 22.000 mA or V 1000 = 1 unit
16.57 AI3 scaled value Real -32768.000 … 32767.000 - 1000 = 1
16.58 AI3 force data Real -22.000 … 22.000 mA or V 1000 = 1 unit
16.59 AI3 HW switch position List --1 = 1
16.60 AI3 unit selection List --1 = 1
16.61 AI3 filter gain List 0…7 - 1 = 1
16.62 AI3 filter time Real 0.000 … 30.000 s 1000 = 1 s
16.63 AI3 min Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
16.64 AI3 max Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
16.65 AI3 scaled at AI3 min Real -32768.000 … 32767.000 - 1000 = 1
16.66 AI3 scaled at AI3 max Real -32768.000 … 32767.000 - 1000 = 1
Common parameters for AOx (16.01 Module 3 type = FIO-11 or FAIO -01 )
16.71 AO force selection PB 00000000h…FFFFFFFFh - 1 = 1
AO1 (16.01 Module 3 type = FIO-11 or FAIO-01)
16.76 AO1 actual value Real 0.000 … 22.000 mA 1000 = 1 mA
16.77 AO1 source Analog
src
--1 = 1
16.78 AO1 force data Real 0.000 … 22.000 mA 1000 = 1 mA
16.79 AO1 filter time Real 0.000 … 30.000 s 1000 = 1 s
16.80 AO1 source min Real -32768.0 … 32767.0 - 10 = 1
16.81 AO1 source max Real -32768.0 … 32767.0 - 10 = 1
16.82 AO1 out at AO1 src min Real 0.000 … 22.000 mA 1000 = 1 mA
16.83 AO1 out at AO1 src max Real 0.000 … 22.000 mA 1000 = 1 mA
AO2 (16.01 Module 3 type = FAIO-01)
16.86 AO2 actual value Real 0.000 … 22.000 mA 1000 = 1 mA
16.87 AO2 source Analog
src
--1 = 1
16.88 AO2 force data Real 0.000 … 22.000 mA 1000 = 1 mA
16.89 AO2 filter time Real 0.000 … 30.000 s 1000 = 1 s
16.90 AO2 source min Real -32768.0 … 32767.0 - 10 = 1
16.91 AO2 source max Real -32768.0 … 32767.0 - 10 = 1
16.92 AO2 out at AO2 src min Real 0.000 … 22.000 mA 1000 = 1 mA
16.93 AO2 out at AO2 src max Real 0.000 … 22.000 mA 1000 = 1 mA
19 Operation mode
19.01 Actual operation mode List --1 = 1
19.11 Ext1/Ext2 selection Binary
src
--1 = 1
19.12 Ext1 control mode List 1…6 - 1 = 1
No. Name Type Range Unit FbEq32
