522 Additional parameter data

19.14 Ext2 control mode List 1…6 - 1 = 1

19.16 Local control mode List 0…1 - 1 = 1

19.17 Local control disable List 0…1 - 1 = 1

19.20 Scalar control reference unit List 0…1 - 1 = 1

20 Start/stop/direction

20.01 Ext1 commands List --1 = 1

20.02 Ext1 start trigger type List 0…1 - 1 = 1

20.03 Ext1 in1 source Binary

src

--1 = 1

20.04 Ext1 in2 source Binary

src

--1 = 1

20.05 Ext1 in3 source Binary

src

--1 = 1

20.06 Ext2 commands List --1 = 1

20.07 Ext2 start trigger type List 0…1 - 1 = 1

20.08 Ext2 in1 source Binary

src

--1 = 1

20.09 Ext2 in2 source Binary

src

--1 = 1

20.10 Ext2 in3 source Binary

src

--1 = 1

20.11 Run enable stop mode List 0…2 - 1 = 1

20.12 Run enable 1 source Binary

src

--1 = 1

20.19 Enable start command Binary

src

--1 = 1

20.23 Positive speed enable Binary

src

--1 = 1

20.24 Negative speed enable Binary

src

--1 = 1

20.25 Jogging enable Binary

src

--1 = 1

20.26 Jogging 1 start source Binary

src

--1 = 1

20.27 Jogging 2 start source Binary

src

--1 = 1

20.30 Enable signals warning

function

PB 00b…11b - 1 = 1

21 Start/stop mode

21.01 Start mode List 0…3 - 1 = 1

21.02 Magnetization time Real 0…10000 ms 1 = 1 ms

21.03 Stop mode List 0…2 - 1 = 1

21.04 Emergency stop mode List 0…2 - 1 = 1

21.05 Emergency stop source Binary

src

--1 = 1

21.06 Zero speed limit Real 0.00 … 30000.00 rpm 100 = 1 rpm

No. Name Type Range Unit FbEq32
