ABB ACS880-104

Parameters 219
14.76 AO1 actual value (Visible when 14.01 Module 1 type = FIO-11 or FA IO-0 1)
Displays the value of AO1 in mA.
This parameter is read-only.
-
0.000 … 22.000 mA Value of AO1. 1000 = 1 mA
14.77 AO1 source (Visible when 14.01 Module 1 type = FIO-11 or FA I O - 0 1)
Selects a signal to be connected to analog output AO1.
Alternatively, sets the output to excitation mode to feed a
constant current to a temperature sensor.
Zero
Zero None. 0
Motor speed used 01.01 Motor speed used (page 152). 1
Output frequency 01.06 Output frequency (page 152). 3
Motor current 01.07 Motor current (page 152). 4
Motor torque 01.10 Motor torque (page 152). 6
DC voltage 01.11 DC voltage (page 152). 7
Power inu out 01.14 Output power (page 153). 8
Speed ref ramp in 23.01 Speed ref ramp input (page 257). 10
Speed ref ramp out 23.02 Speed ref ramp output (page 257). 11
Speed ref used 24.01 Used speed reference (page 263). 12
Torq ref used 26.02 Torque reference used (page 279). 13
Freq ref used 28.02
Frequency ref ramp output (page 285). 14
Process PID out 40.01 Process PID output actual (page 341). 16
Process PID fbk 40.02 Process PID feedback actual (page 341). 17
Process PID act 40.03 Process PID setpoint actual (page 341). 18
Process PID dev 40.04 Process PID deviation actual (page 341). 19
Force Pt100
excitation
The output is used to feed an excitation current to 1…3 Pt100
sensors. See section Motor thermal protection (page 116).
20
Force KTY84
excitation
The output is used to feed an excitation current to a KTY84
sensor. See section Motor thermal protection (page 116 ).
21
Force PTC
excitation
The output is used to feed an excitation current to 1…3 PTC
sensors. See section Motor thermal protection (page 116).
22
Force Pt1000
excitation
The output is used to feed an excitation current to 1…3
Pt1000 sensors. See section Motor thermal protection (page
116).
23
AO1 data storage 13.91 AO1 data storage (page 204). 37
AO2 data storage 13.92 AO2 data storage (page 204). 38
Other Source selection (see Terms and abbreviations on page 148). -
14.78 AO1 force data (Visible when 14.01 Module 1 type = FIO-11 or FA IO-0 1)
Forced value that can be used instead of the selected output
signal. See parameter
14.71 AO force selection.
0.000 mA
0.000 … 22.000 mA Forced value of analog output AO1. 1000 = 1 mA
No. Name/Value Description Def/FbEq16
