ABB ACS880-104

206 Parameters
14.08 DI filter time (Visible when 14.01 Module 1 type = FDIO-01)
Defines a filtering time for parameter 14.05 DI status.
10.0 ms
0.8 … 100.0 ms Filtering time for 14.05. 10 = 1 ms
14.08 DIO filter time (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Defines a filtering time for parameter 14.05 DIO status. The
filtering time will only affect the DIOs that are in input mode.
10.0 ms
0.8 … 100.0 ms Filtering time for 14.05. 10 = 1 ms
14.09 DIO1 function (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Selects whether DIO1 of the extension module is used as a
digital input or output.
Input
Output DIO1 is used as a digital output. 0
Input DIO1 is used as a digital input. 1
14.11 DIO1 output source (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Selects a drive signal to be connected to digital input/output
DIO1 of the extension module when parameter 14.09 DIO1
function is set to Output.
Not
energized
Not energized Output is not energized. 0
Energized Output is energized. 1
Ready run Bit 1 of 06.11 Main status word (see page 166). 2
Enabled Bit 0 of 06.16 Drive status word 1 (see page 167). 4
Started Bit 5 of 06.16 Drive status word 1 (see page 167). 5
Magnetized Bit 1 of 06.17 Drive status word 2 (see page 168
). 6
Running Bit 6 of 06.16 Drive status word 1 (see page 167). 7
Ready ref Bit 2 of 06.11 Main status word (see page 166). 8
At setpoint Bit 8 of 06.11 Main status word (see page 166). 9
Reverse Bit 2 of 06.19 Speed control status word (see page 170). 10
Zero speed Bit 0 of 06.19 Speed control status word (see page 170). 11
Above limit Bit 10 of 06.17 Drive status word 2 (see page 168). 12
Warning Bit 7 of 06.11 Main status word (see page 166). 13
Fault Bit 3 of 06.11 Main status word (see page 166). 14
Fault (-1) Inverted bit 3 of 06.11 Main status word (see page 166). 15
Open brake
command
Bit 0 of 44.01 Brake control status (see page 357). 22
Ext2 active Bit 11 of 06.16 Drive status word 1 (see page 167). 23
Remote control Bit 9 of 06.11 Main status word (see page 166). 24
Supervision 1 Bit 0 of 32.01 Supervision status (see page 312). 33
Supervision 2 Bit 1 of 32.01 Supervision status (see page 312). 34
Supervision 3 Bit 2 of 32.01 Supervision status (see page 312). 35
RO/DIO control
word bit0
Bit 0 of 10.99 RO/DIO control word (see page 191). 40
RO/DIO control
word bit1
Bit 1 of 10.99 RO/DIO control word (see page 191). 41
RO/DIO control
word bit2
Bit 2 of 10.99 RO/DIO control word (see page 191). 42
No. Name/Value Description Def/FbEq16
