No. Name/Value Description Def/FbEq16
Bit Name Description
0 Identification run done 1 = Motor identification (ID) run has been performed
1 Magnetized 1 = The motor has been magnetized
2 Torque control 1 = Torque control mode active
3 Speed control 1 = Speed control mode active
4 Power control 1 = Power control mode active
5 Safe reference active 1 = A “safe” reference is being applied by functions such as
parameters 49.05 and 50.02
6 Last speed active 1 = A “last speed” reference is being applied by functions such
as parameters 49.05 and 50.02
7 Loss of reference 1 = Reference signal lost
8 Emergency stop failed 1 = Emergency stop failed (see parameters 31.32 and 31.33)
9 Jogging active 1 = Jogging enable signal is on
10 Above limit 1 = Actual speed, frequency or torque equals or exceeds limit
(defined by parameters 46.31…46.33). Valid in both directions of
rotation.
11 Emergency stop active 1 = An emergency stop command signal is active, or the drive is
stopping after receiving an emergency stop command.
12 Reduced run 1 = Reduced run active (see section Reduced run function on
page 128)
13 Reserved
14 Stop failed 1 = Stopping failed (see parameters 31.37 and 31.38)
15 Reserved
