No. Name/Value Description Def/FbEq16
Bit Name Description
0 Enabled 1 = Both run enable (see par. 20.12) and start enable (20.19) signals are
present, and Safe torque off has not been activated.
Notes:
• In I/O or local control, clearing this bit makes the drive enter the
SWITCH-ON INHIBITED state (see page 638).
• This bit is not affected by the presence of a fault.
1 Inhibited 1 = Start inhibited. See parameters 06.18 and 06.25 for the source of the
inhibiting signal.
2 DC charged 1 = DC circuit has been charged. If present, the DC switch is closed, and
charging switch is open.
0 = Charging not complete. If the inverter unit is not equipped with a DC
switch (option +F286), check setting of 95.09.
3 Ready to
start
1 = Drive is ready to receive a start command
4Following
reference
1 = Drive is ready to follow given reference
5 Started 1 = Drive has been started
6 Modulating 1 = Drive is modulating (output stage is being controlled)
7 Limiting 1 = Any operating limit (speed, torque, etc.) is active
8 Local control 1 = Drive is in local control
9 Network ctrl 1 = Drive is in network control (see page 17)
10 Ext1 active 1 = Control location EXT1 active
11 Ext2 active 1 = Control location EXT2 active
12 Reserved
13 Start request 1 = Start requested
14…15 Reserved
