508 Additional parameter data

06.17 Drive status word 2 PB 0000h…FFFFh - 1 = 1

06.18 Start inhibit status word PB 0000h…FFFFh - 1 = 1

06.19 Speed control status word PB 0000h…FFFFh - 1 = 1

06.20 Constant speed status word PB 0000h…FFFFh - 1 = 1

06.21 Drive status word 3 PB 0000h…FFFFh - 1 = 1

06.25 Drive inhibit status word 2 PB 0000h…FFFFh - 1 = 1

06.29 MSW bit 10 sel Binary

src

--1 = 1

06.30 MSW bit 11 sel Binary

src

--1 = 1

06.31 MSW bit 12 sel Binary

src

--1 = 1

06.32 MSW bit 13 sel Binary

src

--1 = 1

06.33 MSW bit 14 sel Binary

src

--1 = 1

(Parameters 06.36…06.43 only visible when supply unit control activated by 95.20)

06.36 LSU Status Word PB 0000h…FFFFh - 1 = 1

06.39 Internal state machine LSU

PB 0000h…FFFFh - 1 = 1

06.40 LSU CW user bit 0 selection Binary

src

--1 = 1

06.41 LSU CW user bit 1 selection Binary

src

--1 = 1

06.42 LSU CW user bit 2 selection Binary

src

--1 = 1

06.43 LSU CW user bit 3 selection Binary

src

--1 = 1

06.45 Follower CW user bit 0

selection

Binary

src

--1 = 1

06.46 Follower CW user bit 1

selection

Binary

src

--1 = 1

06.47 Follower CW user bit 2

selection

Binary

src

--1 = 1

06.48 Follower CW user bit 3

selection

Binary

src

--1 = 1

06.50 User status word 1 PB 0000h…FFFFh - 1 = 1

06.60 User status word 1 bit 0 sel Binary

src

--1 = 1

06.61 User status word 1 bit 1 sel Binary

src

--1 = 1

06.62 User status word 1 bit 2 sel Binary

src

--1 = 1

06.63 User status word 1 bit 3 sel Binary

src

--1 = 1

06.64 User status word 1 bit 4 sel Binary

src

--1 = 1

No. Name Type Range Unit FbEq32
