ABB ACS880-104

Additional parameter data 513
12.30 AI2 scaled at AI2 max Real -32768.000 … 32767.000 - 1000 = 1
13 Standard AO
13.11 AO1 actual value Real 0.000 … 22.000 mA 1000 = 1 mA
13.12 AO1 source Analog
src
--1 = 1
13.16 AO1 filter time Real 0.000 … 30.000 s 1000 = 1 s
13.17 AO1 source min Real -32768.0 … 32767.0 - 10 = 1
13.18 AO1 source max Real -32768.0 … 32767.0 - 10 = 1
13.19 AO1 out at AO1 src min Real 0.000 … 22.000 mA 1000 = 1 mA
13.20 AO1 out at AO1 src max Real 0.000 … 22.000 mA 1000 = 1 mA
13.21 AO2 actual value Real 0.000 … 22.000 mA 1000 = 1 mA
13.22 AO2 source Analog
src
--1 = 1
13.26 AO2 filter time Real 0.000 … 30.000 s 1000 = 1 s
13.27 AO2 source min Real -32768.0 … 32767.0 - 10 = 1
13.28 AO2 source max Real -32768.0 … 32767.0 - 10 = 1
13.29 AO2 out at AO2 src min Real 0.000 … 22.000 mA 1000 = 1 mA
13.30 AO2 out at AO2 src max Real 0.000 … 22.000 mA 1000 = 1 mA
13.91 AO1 data storage Real -327.68 … 327.67 - 100 = 1
13.92 AO2 data storage Real -327.68 … 327.67 - 100 = 1
14 I/O extension module 1
14.01 Module 1 type List 0…4 - 1 = 1
14.02 Module 1 location Real 1…254 - 1 = 1
14.03 Module 1 status List 0…4 - 1 = 1
DIx (14.01 Module 1 type = FDIO-01)
14.05 DI status PB 00000000h…FFFFFFFFh - 1 = 1
14.06 DI delayed status PB 00000000h…FFFFFFFFh - 1 = 1
14.08 DI filter time Real 0.8 … 100.0 ms 10 = 1 ms
14.12 DI1 ON delay Real 0.00 … 3000.00 s 100 = 1 s
14.13 DI1 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
14.17 DI2 ON delay Real 0.00 … 3000.00 s 100 = 1 s
14.18 DI2 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
14.22 DI3 ON delay Real 0.00 … 3000.00 s 100 = 1 s
14.23 DI3 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
Common parameters for DIOx (14.01 Module 1 type = FIO-01 or FIO-11)
14.05 DIO status PB 00000000h…FFFFFFFFh - 1 = 1
14.06 DIO delayed status PB 00000000h…FFFFFFFFh - 1 = 1
DIO1/DIO2 (14.01 Module 1 type = FIO-01 or FIO-11)
14.08 DIO filter time Real 0.8 … 100.0 ms 10 = 1 ms
14.09 DIO1 function List 0…1 - 1 = 1
14.11 DIO1 output source Binary
src
--1 = 1
No. Name Type Range Unit FbEq32
