ABB ACS880-104

512 Additional parameter data
11.10 DIO2 output source Binary
src
-1 = 1
11.11 DIO2 ON delay Real 0.0 … 3000.0 s 10 = 1 s
11.12 DIO2 OFF delay Real 0.0 … 3000.0 s 10 = 1 s
11.38 Freq in 1 actual value Real 0…16000 Hz 1 = 1 Hz
11.39 Freq in 1 scaled Real -32768.000 … 32767.000 - 1000 = 1
11.42 Freq in 1 min Real 0…16000 Hz 1 = 1 Hz
11.43 Freq in 1 max Real 0…16000 Hz 1 = 1 Hz
11.44 Freq in 1 at scaled min Real -32768.000 … 32767.000 - 1000 = 1
11.45 Freq in 1 at scaled max Real -32768.000 … 32767.000 - 1000 = 1
11.54 Freq out 1 actual value Real 0…16000 Hz 1 = 1 Hz
11.55 Freq out 1 source Analog
src
--1 = 1
11.58 Freq out 1 src min Real -32768.000 … 32767.000 - 1000 = 1
11.59 Freq out 1 src max Real -32768.000 … 32767.000 - 1000 = 1
11.60 Freq out 1 at src min Real 0…16000 Hz 1 = 1 Hz
11.61 Freq out 1 at src max Real 0…16000 Hz 1 = 1 Hz
11.81 DIO filter time Real 0.3 … 100.0 ms 10 = 1 ms
12 Standard AI
12.01 AI tune enum 0…4 -
12.03 AI supervision function List 0…4 - 1 = 1
12.04 AI supervision selection PB 0000h…FFFFh - 1 = 1
12.05 AI supervision force PB 0000h…FFFFh - 1 = 1
12.11 AI1 actual value Real -22.000 … 22.000 mA or V 1000 = 1 unit
12.12 AI1 scaled value Real -32768.000 … 32767.000 - 1000 = 1
12.15 AI1 unit selection List --1 = 1
12.16 AI1 filter time Real 0.000 … 30.000 s 1000 = 1 s
12.17 AI1 min Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
12.18 AI1 max Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
12.19 AI1 scaled at AI1 min Real -32768.000 … 32767.000 - 1000 = 1
12.20 AI1 scaled at AI1 max Real -32768.000 … 32767.000 - 1000 = 1
12.21 AI2 actual value Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
12.22 AI2 scaled value Real -32768.000 … 32767.000 - 1000 = 1
12.25 AI2 unit selection List --1 = 1
12.26 AI2 filter time Real 0.000 … 30.000 s 1000 = 1 s
12.27 AI2 min Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
12.28 AI2 max Real -22.000 … 22.000 mA or V 1000 = 1 mA
or V
12.29 AI2 scaled at AI2 min Real -32768.000 … 32767.000 - 1000 = 1
No. Name Type Range Unit FbEq32
