ABB ACS880-104

592 Fault tracing
5093 Rating ID mismatch The hardware of the drive does
not match the information
stored in the memory unit. This
may occur eg. after a firmware
update or memory unit
replacement.
Cycle the power to the drive.
Check the auxiliary code. The auxiliary
code categories are as follows:
1 = PU and CU ratings not the same.
Rating ID has changed.
2 = Parallel connection rating ID has
changed.
3 = PU types not the same in all power
units.
4 = Parallel connection rating ID is active
in a single power unit setup.
5 = It is not possible to implement the
selected rating with the current PUs.
6 = PU rating ID is 0.
7 = Reading PU rating ID or PU type
failed on PU connection.
8 = PU not supported (illegal rating ID).
With parallel connection faults (BCU
control unit), the format of the auxiliary
code is 0X0Y. “Y” indicates the auxiliary
code category, “X” indicates the first
faulty PU channel in hexadecimal (1…C).
(With a ZCU control unit, “X” can be 1 or
2 but this is irrelevant to the fault.)
5094 Measurement circuit
temperature
Problem with internal
temperature measurement of
the drive.
See A5EA Measurement circuit
temperature (page 573).
5681 PU communication The way the control unit is
powered does not correspond
to parameter setting.
Check setting of 95.04 Control board
supply.
Communication errors
detected between the drive
control unit and the power unit.
Check the connection between the
control unit and the power unit.
Check the auxiliary code (format XXXY
YYZZ). With parallel-connected modules,
“Y YY” specifies the affected BCU control
unit channel (0: broadcast). “ZZ”
specifies the error source (1: Transmitter
side [link error], 2: Transmitter side [no
communication], 3: Receiver side [link
error], 4: Receiver side [no
communication], 5: Transmitter FIFO
error [see “XXX”], 6: Module [xINT board]
not found, 7: BAMU board not found).
“XXX” specifies the transmitter FIFO
error code (1: Internal error [invalid call
parameter], 2: Internal error
[configuration not supported],
3: Transmission buffer full).
5682 Power unit lost Connection between the drive
control unit and the power unit
is lost.
Check the connection between the
control unit and the power unit.
5690 PU communication
internal
Internal communication error. Contact your local ABB representative.
5691 Measurement circuit
ADC
Measurement circuit fault. Contact your local ABB representative,
quoting the auxiliary code.
Code
(hex)
Fault Cause What to do
