ABB ACS880-104

604 Fault tracing
0001 Maximum current limit too low. Check settings of parameters 99.06
Motor nominal current and 30.17
Maximum current. Make sure that
30.17 > 99.06.
Check that the drive is dimensioned
correctly according to the motor.
0002 Maximum speed limit or
calculated field weakening
point too low.
Check settings of parameters
• 30.11 Minimum speed
• 30.12 Maximum speed
• 99.07 Motor nominal voltage
• 99.08 Motor nominal frequency
• 99.09 Motor nominal speed.
Make sure that
• 30.12 > (0.55 × 99.09) >
(0.50 × synchronous speed)
• 30.11 <
0, and
• supply voltage >
(0.66 × 99.07).
0003 Maximum torque limit too low. Check settings of parameter 99.12 Motor
nominal torque, and the torque limits in
group 30 Limits.
Make sure that the maximum torque limit
in force is greater than 100%.
0004 Current measurement
calibration did not finish within
reasonable time.
Contact your local ABB representative.
0005…0008 Internal error. Contact your local ABB representative.
0009 (Asynchronous motors only)
Acceleration did not finish
within reasonable time.
Contact your local ABB representative.
000A (Asynchronous motors only)
Deceleration did not finish
within reasonable time.
Contact your local ABB representative.
000B (Asynchronous motors only)
Speed dropped to zero during
ID run.
Contact your local ABB representative.
000C (Permanent magnet motors
only) First acceleration did not
finish within reasonable time.
Contact your local ABB representative.
000D (Permanent magnet motors
only) Second acceleration did
not finish within reasonable
time.
Contact your local ABB representative.
000E…0010 Internal error. Contact your local ABB representative.
FF7E Follower A follower drive has tripped. Check the auxiliary code. Add 2 to the
code to find out the node address of the
faulted drive.
Correct the fault in the follower drive.
FF81 FB A force trip A fault trip command has been
received through fieldbus
adapter A.
Check the fault information provided by
the PLC.
FF82 FB B force trip A fault trip command has been
received through fieldbus
adapter B.
Check the fault information provided by
the PLC.
Code
(hex)
Fault Cause What to do
