NoteArticle numberSpare part
Used with protection class IP67.
Replace if damaged.
3HAC067833-001Gasket for housing cover
Used with protection class IP67.
Replace if damaged.
3HAC067832-001Gasket for lower arm cover
Used for CRB 1300-11/0.9.
Used with protection class IP67.
Replace if damaged.
3HAC067822-001Gasket for swing support, short
Used for CRB 1300-10/1.15 and
CRB 1300-7/1.4.
Used with protection class IP67.
Replace if damaged.
3HAC067823-001Gasket for swing support, long
Used for CRB 1300-11/0.9.
Used with protection class IP67.
Replace if damaged.
3HAC067824-001Gasket for swing cover, short
Used for CRB 1300-10/1.15 and
CRB 1300-7/1.4.
Used with protection class IP67.
Replace if damaged.
3HAC067825-001Gasket for swing cover, long
Used with protection class IP67.
Replace if damaged.
3HAC067821-001Gasket for swing top cover
Used with protection class IP67.
Replace if damaged.
3HAC032050-001Seal bolt
Required tools and equipment
NoteArticle numberEquipment
Content is defined in section
Standard toolkit on page 716.
-Standard toolkit
Delivered as a set of calibration
tools.
Required if Axis Calibration is the
valid calibration method for the
robot.
3HAC074119-001Calibration toolbox, Axis Calibra-
tion
Used to release the motor brakes.-24 VDC power supply
The capacity of the vessel must
be sufficient to take the complete
amount of oil.
-Oil collecting vessel
Used for draining and filling oil to
axis-1 gearbox.
Connector specification: G3/8
-Connector for quick coupling, with
outlet pipe
Includes pump with outlet pipe.-Oil dispenser
Included in special toolkit
3HAC076396-001.
-Quick coupling assembly tool
Included in special toolkit
3HAC076396-001.
-Axis-1 gearbox assembly cap
Included in special toolkit
3HAC076396-001.
-Axis-1 gearbox/motor sealing
pressfit tool
Continues on next page
262 Product manual - CRB 1300
3HAC083111-001 Revision: B
© Copyright 2022-2023 ABB. All rights reserved.
5 Repair
5.4.1 Replacing the base
Continued
