ABB CRB 1300 - Page 80

D
40
(2x)M5x10
D
340
127,4
62,5
E
F
60
(2x)M4x8
E
20
(4x)M4x8
F
F
xx2200000987
Continues on next page
80 Product manual - CRB 1300
3HAC083111-001 Revision: B
© Copyright 2022-2023 ABB. All rights reserved.
3 Installation and commissioning
3.3.6 Fitting equipment on the robot (robot dimensions)
Continued
