Parameters 427
SLSx.23 SLS2 trip limit
positive
Sets the SLS2 positive speed limit that trips
the drive.
0.0 rpm
0.0…35880.0 rpm Speed
SLSx.24 SLS2 output Sets the digital output for SLS2 function.
Active when SLS2 function is active and the
motor speed is below the SLS2 limit (that is,
when the SLS2 monitoring is on).
None
None No output connected
DO X113:7 & X114:7 Redundant output X113:7 & X114:7
DO X113:8 & X114:8 Redundant output X113:8 & X114:8
DO X113:9 & X114:9 Redundant output X113:9 & X114:9
DO X113:7 Single output X113:7
DO X113:8 Single output X113:8
DO X113:9 Single output X113:9
DO X114:7 Single output X114:7
DO X114:8 Single output X114:8
DO X114:9 Single output X114:9
SLSx.27 Mute time for SLS2 Sets the SLS2 specific mute time for limit hit
situations.
This parameter is effective only with the safe
speed estimate.
0 ms
0…10000 ms
SLSx.31 SLS3 input Sets the digital input for the SLS3 function. None
None No input connected
DI X113:1 & X114:1 Redundant input X113:1 & X114:1
DI X113:2 & X114:2 Redundant input X113:2 & X114:2
DI X113:3 & X114:3 Redundant input X113:3 & X114:3
DI X113:4 & X114:4 Redundant input X113:4 & X114:4
DI X113:1 Single input X113:1
DI X113:2 Single input X113:2
DI X113:3 Single input X113:3
DI X113:4 Single input X113:4
DI X114:1 Single input X114:1
DI X114:2 Single input X114:2
DI X114:3 Single input X114:3
DI X114:4 Single input X114:4
SLSx.32 SLS3 trip limit
negative
SLS3 negative speed limit that trips the
drive.
0.0 rpm
-35880.0 …0.0 rpm Speed
SLSx.33 SLS3 trip limit
positive
Sets the SLS3 positive speed limit that trips
the drive.
0.0 rpm
0.0…35880.0 rpm Speed
Index Name/Value Description Factory
default
