ABB FSPS-21 - FSPS-21 PROFIsafe Profiles (ABB_PS3)

DescriptionNameBitOctet
Octet 1 (LSB) of 24 bit CRCCRC bit 77N
i
+3
…
CRC bit 00
￭ FSPS-21 PROFIsafe profiles
The content of the F-Input and F-Output user data is configured with FSPS-21 specific
PROFIsafe profiles. The FSPS-21 module supports the ABB_PS3 profile.
The ABB_PS3 profile provides the functionality to control and monitor the safety functions.
ABB_PS3 profile F-Input user data
This table shows the bit order of the F-Input user data, which is included in the PROFIsafe
message sent from the FSPS-21 module to the safety PLC. For all the bits in the F-Input
data, one (1) means active and zero (0) non-active.
PROFIsafe frame from F-Device to F-Host
CRC 2Status byteF-Input data
3 octets1 octet2 octets as bits
LSB Octet n...MSB Octet 0Octet 0Octet 1Octet 0
F-Input data
DescriptionNameBitOctetType
1=Safe state, 0=Operational stateDevice_sta-te00Unsigned8
(used as bits)
StateBit 2Bit 1
Device_mo-de_bit_11
2
Run00Device_mo-de_bit_2
Fault detected01
Fail-safe10
Reserved *)11
1=Both STO signals 24V, 0=otherwiseSTO_signals_active3
1=STO function active, 0=not activeSTO_active4
1=SS1-t function active, 0=not activeSS1-t_active5
Reserved *)6
Reserved *)7
PROFIsafe 115
