Example
value
DescriptionName/ValueIndex
Selects one of the PNIO profiles.FBA A/B PAR2
(PROTOCOL/ PRO-
FILE)
51/54.02
11Profile PNIO ABB Pro is selectedPNIO ABB Pro
Sets the Ethernet communication rate.FBA A/B PAR2
(COMMRATE )
51/54.03
0Ethernet communication rate is negotiated automat-
ically by the device.
Auto
Static IPThe user can set the IP configuration for the network
in these parameters or in the PLC project.
IP CONFIGURA-
TION
51/54.04 ... 13
0
Shows the telegram type for the selected I/O com-
munication.
Telegram type51/54.20
This parameter is read-only.
4PPO Type 4PPO4
Enables/disables the sending of diagnostic mes-
sages to the PROFINET network.
Diagnostic alarm51/54.21
0Diagnostic messages are sent.Enabled
1Sets the PROFIsafe destination address, that is, the
address of the FSPS-21 module in the safety com-
munication network.
F Destination Ad-
dress
51/54.24
This address must be the same as is set in the F-
Parameters for the PROFIsafe module properties
(F_Dest_Add).
12Allows defining the PROFINET station name.PN Name Index51/54.25
By default this value is 0 and the station name is set
in PLC project. When the value is set to other than
0, the PROFINET station name is overwritten in the
format “abbdrive-xx”, where xx is the value of the
parameter name index.
Example: Setting this value to 12 results in the name
“abbdrive-12”.
Note:
During every boot the FSPS-21 module checks the
value of PN Name Index:
• If the value is not Zero then the active PN Name
Index overrides the PROFINET station name.
• If the new name is set by DCP Set command as
permanent, the new name is used and stored to
flash. The PN Name Index parameter value is not
changed, so after next boot, the name is taken
according to the PN Name Index.
• If the new name is set by DCP Set command as
temporary, the new name is used and the empty
name is stored to flash. The PN Name Index
parameter value is not changed, so after next boot,
the name is taken according to the PN Name In-
dex.
• The PROFINET DCP factory reset also resets the
PN Name Index value to default (0).
PROFIsafe 125
