Control elements and application parameter
"Page link" control element
Product manual 2CKA001473B5023
105
2.12 "Page link" control element
2.12.1 Name of the control element
Options: <Name>
Naming of the page link control element.
The length of the name is limited to 36 characters.
2.12.2 Function of the control element
Options: Not defined (grey)
Light (yellow)
Blind (blue)
Temperature (orange)
Scene (magenta)
Alarm (red)
Feedback (green)
The parameter is used to specify the colour of the function line.
"Not defined (grey)" has been made available for functions of this type.
2.12.3 Size of the button
Options: 1 column
2 columns
The parameter is used to specify whether the control element occupies one column (one button
or control frame) or two columns (two buttons or control frames).
2.12.4 Linked with page
Options: <Main operating page>
<Operating page x>
<Application page x>
The parameter is used to specify with which operating or application page the page link control
element is linked.
– <Main operating page>: Start page or homepage.
– <Operating page x>: All operating pages (start pages and operating pages for rooms) which
were created via the DCA commissioning tool can be selected.
– <Application page x>: The following application pages can be selected: system settings,
door communication, fault and alarm messages or time programs.
