Commissioning of the KNX Function via DCA (from ETS5)
Product manual 2CKA001473B5023
11
1 Commissioning of the KNX Function via DCA (from ETS5)
Commissioning the KNX function of the IP touch via the plug-in ETS5 commissioning tool DCA.
Notice
For further commissioning, the configuration and automation software ETS5
must be installed and ready for operation on the computer used for configuration
and commissioning.
1.1 Integration into the KNX system (ETS)
Notice
The device meets KNX guidelines and can be used as product of the KNX
system. Detailed expert knowledge for understanding by means of KNX training
is assumed, especially with regard to the commissioning software ETS.
1.1.1 Prerequisites
DCA version
The minimum requirement is the use of DCA from version 1.1.1.4.
ETS version
The minimum requirement is the use of ETS from version 5.
Physical connection in KNX
The physical connection is made by means of a KNX IPR/S, IPS/S or IPR/S (Secure) or IPS/S
(Secure).
SD card
The following SD card types are supported:
Type: Micro SDHC
Capacity: 4 … 32 G
Speed: Class 10
File system: Fat32
