7-2 Specifications MN1941WEN
7.1.4 Digital inputs
7.1.5 Digital outputs
7.1.6 Relay output
Description Unit Value
Type Opto-isolated
USR V+ supply voltage
Nominal
Minimum
Maximum
VDC
24
12
30
Input voltage
Active
Inactive
VDC
> 12
< 2
Input current
(maximum per input, USR V+ = 24 V)
mA 7
Sampling interval ms 1
Description Unit Value
USR V+ supply voltage
Nominal
Minimum
Maximum
VDC
24
12
30
Output curren
Max. source per output, one output on
Max. source per output, all outputs on
Maximum total output current
mA DOUT0-7 DOUT8-11
350 350
62.5 125
500 500
Update interval (Mint) Immediate
Switching time
No load on output
With 7 mA or greater load
100 ms
10 µs
All models Unit All models
Contact rating (resistive) 1 A @ 24 V DC
or
0.25 A @ 30 V AC
Operating time (max) ms 5
