MN1941WEN Basic Installation 3-3
3.1.3 Other requirements for installation
The NextMove e100 requires a 24 V DC power supply capable of supplying 2 A
continuously. It is recommended that a separate fused 24 V DC supply is provided for
the NextMove e100, with the fuse rated at 4 A maximum. If digital outputs are to be used,
a supply will be required to drive them - see section 4.3.2.
A PC that fulfills the following specification:
* The Ethernet configuration used by a normal office PC is not suitable for direct
communication with the NextMove e100. It is recommended to install a separate dedicated
Ethernet adapter in the PC, which can be configured for use with the NextMove e100. See
section 5.1.7.
A USB cable or RS485/422 serial cable.
Your PC operating system user manual might be useful if you are not familiar with
Windows.
Minimum specification
Processor 1 GHz
RAM 512 MB
Hard disk space 2 GB
CD-ROM A CD-ROM drive
Serial port
USB port
or
RS232 or RS485 serial port, or Ethernet* port
Screen 1024 x 768, 16-bit color
Mouse A mouse or similar pointing device
Operating
system
Windows XP or newer, 32-bit or 64-bit
