MN1941WEN Specifications 7-1
Specifications
7 Specifications
7.1 Introduction
This section provides technical specifications of the NextMove e100.
7.1.1 Input power
7.1.2 Analog inputs
7.1.3 Analog outputs
Description Value
Input power
Nominal input voltage
Power consumption
24 V DC (±20%)
50 W (2 A @24 V)
Description Unit Value
Type Differential
Common mode voltage range V DC ±10
Input impedance kΩ 120
Input ADC resolution bits 12 (includes sign bit)
Equivalent resolution (±10 V input) mV ±4.9
Sampling interval µs 500 (both inputs enabled)
250 (one input disabled)
Description Unit Value
Type Bipolar
Output voltage range V DC ±10
Output current (per output) mA 2.5
Output DAC resolution bits 12
Equivalent resolution mV ±4.9
Update interval ms 1
7
