7-4 Specifications MN1941WEN
7.1.11 CAN interface
7.1.12Environmental
See also section 3.1.1.
7.1.13Weights and dimensions
Description Unit Value
Signal 2-wire, isolated
Channels 1
Protocol CANopen
Bit rates Kbit/s
10, 20, 50, 100, 125, 250, 500, 1000
Description Unit
Operating temperature range Min Max
°C
°F
0
+32
+45
+113
Maximum humidity % 80% for temperatures up to 31 °C (87 °F)
decreasingly linearly to 50% relative
humidity at 45 °C (113 °F),
non-condensing
Maximum installation altitude
(above m.s.l.)
m
ft
2000
6560
Shock 10 G according to
IEC 60068-2-6/27 or equivalent
Vibration 1 G, 10-150 Hz according to
IEC 60068-2-6/27 or equivalent
Description Value
Weight Approximately 700 g (1.5 lb)
Nominal overall dimensions 250 mm x 140 mm x 40.3 mm
(9.84 in x 5.51 in x 1.59 in)
