MN1941WEN Introduction 2-3
2.2 Receiving and inspection
When you receive your NextMove e100, there are several things you should do immediately:
1. Check the condition of the packaging and report any damage immediately to the carrier
that delivered your NextMove e100.
2. Remove the NextMove e100 from the shipping container and remove all packing
material. The container and packing materials may be retained for future shipment.
3. Verify that the catalog number of the NextMove e100 you received is the same as the
catalog number listed on your purchase order. The catalog/part number is described in
the next section.
4. Inspect the NextMove e100 for external damage during shipment and report any
damage to the carrier that delivered it.
5. If the NextMove e100 is to be stored for several weeks before use, be sure that it is
stored in a location that conforms to the storage humidity and temperature specifications
shown in section 3.1.1.
2.2.1 Identifying the catalog number
Different models of NextMove e100 are available. As a reminder of which product has been
installed, it is a good idea to write the catalog number in the space provided below.
A description of the catalog numbers are shown in the following table:
Note: The x represents a letter indicating the hardware revision. This does not affect
the capabilities of the NextMove e100 unless otherwise stated.
Catalog number Description
NXE100-1608Dx 8 axes, RS422 differential stepper outputs.
NXE100-1608Sx 8 axes, open collector (single-ended) stepper outputs.
NXE100-1612Dx 12 axes, RS422 differential stepper outputs.
NXE100-1612Sx 12 axes, open collector (single-ended) stepper outputs.
NXE100-1616Dx 16 axes, RS422 differential stepper outputs.
NXE100-1616Sx 16 axes, open collector (single-ended) stepper outputs.
NextMove e100 catalog number: NXE100-16____D_ or NXE100-16____S_
Installed in: ______________________________________ Date: _____________
