ABB PST Series - 10:46 Frequency fault, type of operation; 10:47 Heat sink over-temperature fault, type of operation

141
1SFC132003M0201
)XQFWLRQV
&KDSWHU
 )UHTXHQF\IDXOWW\SHRIRSHUDWLRQ
3DWKLQPHQX
0HQX6(77,1*6)XQFWLRQDO6HWWLQJV
)DXOWV)UHT)2S
This parameter makes it possible to select between two
different actions of the softstarter if the frequency is out of
range (frequency fault).
 +HDWVLQNRYHUWHPSHUDWXUHIDXOW
W\SHRIRSHUDWLRQ
3DWKLQPHQX
0HQX6(77,1*6)XQFWLRQDO6HWWLQJV
)DXOWV+67HPS2S
This parameter makes it possible to select between two
different actions if the heat sink temperature of the
softstarter is too high.
Stop–M The motor stops and a manual reset is
required before restart.
Stop–A The motor stops and an automatic reset is
performed when the fault disappears.
3DUDPHWHU
WH[W
'HIDXOWYDOXH 6HWWLQJUDQJH 'HVFULSWLRQ
Freq F Op Stop–M Stop–M, Stop–A Type of operation
for frequency fault
Stop–M The motor stops and a manual reset is
required before restart.
Stop–A The motor stops and an automatic reset is
performed when the fault disappears.
3DUDPHWHU
WH[W
'HIDXOWYDOXH 6HWWLQJUDQJH 'HVFULSWLRQ
HS Temp
Op
Stop–M Stop–M, Stop–A Type of opera-
tion for heat sink
over temperature
fault
