INHIBOUT
If the INHIBIT input is activated it is reported on the INHIBOUT output.
INPROGR
Indicates that an auto recloser sequence is in progress, from start until circuit
breaker close command.
READY
Indicates that the auto recloser is ready for a new and complete auto reclosing
sequence. It can be connected to the zone extension if a line protection should have
extended zone reach before auto reclosing.
SETON
Indicates that auto recloser is switched on and operative.
SUCCL
If the circuit breaker closing command is given and the circuit breaker is closed
within the set time interval tUnsucCl, the SUCCL output is activated after the set
time interval tSuccessful.
SYNCFAIL
The SYNCFAIL
output indicates that the auto recloser is inhibited because the
synchrocheck or energizing check condition has not been fulfilled within the set
time interval, tSync. Also ABORTED output will be activated.
UNSUCCL
Indicates unsuccessful reclosing.
Connection and setting examples
Figure
73 shows an example of how to connect the auto recloser.
