ABB RET615 - Detailed Function Mappings

2.3.1.2 CTRL.CBCILO1 Circuit breaker enable signals (1)
Table 5: CTRL.CBCILO1 Circuit breaker enable signals (1)
BitA
RegA IEC 61850 name SA name Description Values
CTRL.CBCILO1
2824 176.08 .EnaOpn.stVal ENA_OPEN Open enabled 1=Enabled
2825 176.09 .EnaCls.stVal ENA_CLOSE Close enabled 1=Enabled
2.3.1.3 CTRL.CBCSWI1 Circuit breaker (1) mom. position
Table 6: CTRL.CBCSWI1 Circuit breaker (1) mom. position
BitA RegA IEC 61850 name SA name Description Values
CTRL.CBCSWI1 POSITION
2804 175.04 .Pos.stVal.Close - Close bit 1=Close
2805 175.05 .Pos.stVal.Open - Open bit 1=Open
2806 175.06 .Pos.stVal.Fault - Fault bit 1=Pos(00/11)
2834 177.02 .SynItlByps.stVal ITL_BYPASS Interlock bypass 1=Bypass
2835 177.03 .mcd
2.3.1.4 CTRL.CBCSWI1 Circuit breaker (1) mom+mcd position
Table 7: CTRL.CBCSWI1 Circuit breaker (1) mom+mcd position
BitA
RegA IEC 61850 name SA name Description Values
CTRL.CBCSWI1 POSITION
2816 176.00 .Pos.stVal.Close Close bit 1=Close
2817 176.01 .mcd
2818 176.02 .Pos.stVal.Open Open bit 1=Open
2819 176.03 .mcd
2820 176.04 < reserved >
2821 176.05 < reserved >
2822 176.06 .Pos.stSeld SELECTED CB selected for control 1=Selected
2823 176.07 .mcd
2.3.1.5 CTRL.CBXCBR1 Circuit-breaker control (1)
Table 8: CTRL.CBXCBR1 Circuit-breaker control (1)
BitA
RegA IEC 61850 name SA name Description Values
CTRL.CBXCBR1
2836 177.04 .BlkOpn.stVal BLK_OPEN Open blocked 1=Blocked
2837 177.05 .mcd
Table continues on next page
Section 2 1MRS756878 H
Modbus data mappings
18 RET615
Point List Manual
