2.4.1.49 LD0.VSMSQI1 Sequence voltage measurement (1)
Table 152: LD0.VSMSQI1 Sequence voltage measurement (1)
RegA
Type Scale IEC 61850 name SA name Description Values
LD0.VSMSQI1 Sequence of voltages
148 u16 1000 .SeqA.c1.instCVal.mag U1_INST Positive amplitude
0.00...4.00
[xUn]
149 u16 1000 .SeqA.c2.instCVal.mag U2_INST Negative amplitude
0.00...4.00
[xUn]
150 u16 1000 .SeqA.c2.instCVal.mag U3_INST Zero amplitude
0.00...4.00
[xUn]
2.4.1.50 LD0.XARGGIO130 RTD input values
Table 153: LD0.XARGGIO130 RTD input values
RegA Type Scale IEC 61850 name SA name Description Values
LD0.XARGGIO130
2091 i16 1 .AnIn1.mag AI_VAL1 RTD input 1 in ohms -/+ 10000.00
2092 i16 1 .AnIn2.mag AI_VAL2 RTD input 2 in ohms -/+ 10000.00
2093 i16 1 .AnIn3.mag AI_VAL3 RTD input 3 in ohms -/+ 10000.00
2094 i16 1 .AnIn4.mag AI_VAL4 RTD input 4 in ohms -/+ 10000.00
2.4.1.51 LD0.XRGGIO130 RTD input values
Table 154: LD0.XRGGIO130 RTD input values
RegA
Type Scale IEC 61850 name SA name Description Values
LD0.XRGGIO130
2091 i16 1 .AnIn1.mag AI_VAL1 RTD input 1 in ohms -/+ 10000.00
2092 i16 1 .AnIn2.mag AI_VAL2 RTD input 2 in ohms -/+ 10000.00
2093 i16 1 .AnIn3.mag AI_VAL3 RTD input 3 in ohms -/+ 10000.00
2094 i16 1 .AnIn4.mag AI_VAL4 RTD input 4 in ohms -/+ 10000.00
2095 i16 1 .AnIn5.mag AI_VAL5 RTD input 5 in ohms -/+ 10000.00
2096 i16 1 .AnIn6.mag AI_VAL6 RTD input 6 in ohms -/+ 10000.00
2097 i16 1 .AnIn7.mag AI_VAL7 RTD input 7 in ohms -/+ 10000.00
2098 i16 1 .AnIn8.mag AI_VAL8 RTD input 8 in ohms -/+ 10000.00
2.4.2 Unmapped registers
Unmapped registers are register data that have no initial Modbus mapping locations,
but can be added to the user-definable Modbus area using the Communication
Management tool in PCM600. The initial register type settings of these objects have
