2.4.1 Premapped registers
2.4.1.1 Active parameter setting group - read and write
Table 104: Active parameter setting group - read and write
RegA
Type Scale IEC 61850 name SA name Description Values
2301 u16 1 Active setting group 1...6
2.4.1.2 Control structure 1
Table 105: Control structure 1
RegA Type Scale IEC 61850 name SA name Description Values
8001 Execute register 1
8002 Password reg 1 acc to setting
8003 Password reg 2 acc to setting
8004 Control register < single bit >
8005 Confirm register < single bit >
2.4.1.3 Control structure 2
Table 106: Control structure 2
RegA
Type Scale IEC 61850 name SA name Description Values
8006 Execute register 1
8007 Password reg 1 acc to setting
8008 Password reg 2 acc to setting
8009 Control register < single bit >
8010 Confirm register < single bit >
2.4.1.4 Control structure 3
Table 107: Control structure 3
RegA
Type Scale IEC 61850 name SA name Description Values
8011 Execute register 1
8012 Password reg 1 acc to setting
8013 Password reg 2 acc to setting
8014 Control register < single bit >
8015 Confirm register < single bit >
1MRS756878 H Section 2
Modbus data mappings
RET615 55
Point List Manual
