2.3.1.48 LD0.PHPTOV1 Three-phase overvoltage protection (1)
Table 51: LD0.PHPTOV1 Three-phase overvoltage protection (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.PHPTOV1
3088 193.00 .Str.general START General start 1=Start
3089 193.01 .mcd
3090 193.02 .Str.phsA Phs A start 1=Start
3091 193.03 .mcd
3092 193.04 .Str.phsB Phs B start 1=Start
3093 193.05 .mcd
3094 193.06 .Str.phsC Phs C start 1=Start
3095 193.07 .mcd
3096 193.08 .Op.general OPERATE General operate 1=Operate
3097 193.09 .mcd
2.3.1.49 LD0.PHPTOV2 Three-phase overvoltage protection (2)
Table 52: LD0.PHPTOV2 Three-phase overvoltage protection (2)
BitA
RegA IEC 61850 name SA name Description Values
LD0.PHPTOV2
3098 193.10 .Str.general START General start 1=Start
3099 193.11 .mcd
3100 193.12 .Str.phsA Phs A start 1=Start
3101 193.13 .mcd
3102 193.14 .Str.phsB Phs B start 1=Start
3103 193.15 .mcd
3104 194.00 .Str.phsC Phs C start 1=Start
3105 194.01 .mcd
3106 194.02 .Op.general OPERATE General operate 1=Operate
3107 194.03 .mcd
2.3.1.50 LD0.PHPTUV1 Three-phase undervoltage protection (1)
Table 53: LD0.PHPTUV1 Three-phase undervoltage protection (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.PHPTUV1
3138 196.02 .Str.general START General start 1=Start
3139 196.03 .mcd
3140 196.04 .Str.phsA Phs A start 1=Start
Table continues on next page
1MRS756878 H Section 2
Modbus data mappings
RET615 35
Point List Manual
