Page #91 background imageLoading...
Page #91 background image
0xA CS IEC 61850 name SA name Description Values
2068 2.08 .MemClr.Oper.ctlVal Clear DR memory 1=Clear
LD0.CMMXU1
2069 2.09 .RecRs.Oper.ctlVal Reset max current1 demands 1=Reset
LD0.PEMMXU1
2070 2.10 .SupDmdRs.Oper.ctlVal Reset energy values 1=Reset
LD0.SCCBR1
2071 2.11 .RsTrvTm.Oper.ctlVal Reset CB travel time 1=Reset
2072 2.12 .RsSprChaTm.Oper.ctlV
al
Reset CB spring charge time 1=Reset
LD0.RESCMMXU1
2073 2.13 .RecRs.Oper.ctlVal Reset Io (1) max demands 1=Reset
LD0.RESVMMXU1
2074 2.14 .RecRs.Oper.ctlVal Reset Uo (1) max demands 1=Reset
LD0.CMMXU2
2075 2.15 .RecRs.Oper.ctlVal Reset max current2 demands 1=Reset
LD0.RESCMMXU2
2076 3.14 .RecRs.Oper.ctlVal Reset Io (2) max demands 1=Reset
2.5.2 CTRL.CBCSWI1 Circuit breaker control (1)
Table 166: CTRL.CBCSWI1 Circuit breaker control (1)
0xA
CS IEC 61850 name SA name Description Values
CTRL.CBCSWI1
2048 1.00 .Pos.Oper.ctlVal Select open 1=Select
2049 1.01 .Pos.Oper.ctlVal Select close 1=Select
2050 1.02 .Pos.Oper.ctlVal Cancel selection 1=Cancel
2051 1.03 .Pos.Oper.ctlVal Execute selection 1=Execute
2052 1.04 .Pos.Oper.ctlVal Direct open 1=Open
2053 1.05 .Pos.Oper.ctlVal Direct close 1=Close
2.5.3 CTRL.DCXSWI1 Disconnector control (1)
Table 167: CTRL.DCXSWI1 Disconnector control (1)
0xA
CS IEC 61850 name SA name Description Values
CTRL.DCCSWI1
2144 7.00 .Pos.Oper.ctlVal Select open 1=Select
2145 7.01 .Pos.Oper.ctlVal Select close 1=Select
2146 7.02 .Pos.Oper.ctlVal Cancel selection 1=Cancel
Table continues on next page
1MRS756878 H Section 2
Modbus data mappings
RET615 85
Point List Manual
