ABB RET615 - LD0.PEMMXU1 Three-Phase Power and Energy Measurement (1); LD0.RESCMMXU1 Residual Current Demand Value (1)

2.4.1.36 LD0.PEMMXU1 Three-phase power and energy measurement (1)
Table 139: LD0.PEMMXU1 Three-phase power and energy measurement (1)
RegA
Type Scale IEC 61850 name SA name Description Values
LD0.PEMMXU1
163 i32 1 .TotW.instMag P_INST Total active power P (high) -/+ 999,999
164 .TotW.instMag (Low word)
165 i32 1 .TotVAr.instMag Q_INST Total reactive power Q (high) -/+ 999,999
166 .TotVAr.instMag (Low word)
167 i32 1 .TotVA.instMag S_INST Total apparent power S (high) -/+ 999,999
168 .TotVA.instMag (Low word)
169 i16 1000 .TotPF.instMag PF_INST Average power factor -1...1
2.4.1.37 LD0.RESCMMXU1 Residual current demand value (1)
Table 140: LD0.RESCMMXU1 Residual current demand value (1)
RegA Type Scale IEC 61850 name SA name Description Values
LD0.RCAVMMXU1 Demand value
1989 u16 1000 .A.res.cVal.mag I_DMD_RES Residual amplitude 0.00…50.0
[xIn]
1990 Year - month
1991 Day - hour
1992 Minute - second
1993 Milliseconds
1994 Time quality
LD0.RCMAMMXU1 Max. demand value
1995 u16 1000 .A.res.cVal.mag Max demand Io Residual amplitude 0.00…50.0
[xIn]
1996 Year - month
1997 Day - hour
1998 Minute - second
1999 Milliseconds
2000 Time quality
LD0.RCMIMMXU1 Min. demand value
u16 1000 .A.res.cVal.mag Min demand Io Residual amplitude 0.00…50.0
[xIn]
Section 2 1MRS756878 H
Modbus data mappings
76 RET615
Point List Manual
