ABB RET615 - LD0.TCSSCBR1 Trip Circuit Supervision (1); LD0.TCSSCBR2 Trip Circuit Supervision (2); LD0.TR2 PTDF1 Stabilized and Instantaneous Differential Protection for Two-Winding Transformers (1)

BitA RegA IEC 61850 name SA name Description Values
2975 185.15 .mcd
2976 186.00 .Op.general OPERATE General operate 1=Operate
2977 186.01 .mcd
2.3.1.61 LD0.TCSSCBR1 Trip circuit supervision (1)
Table 64: LD0.TCSSCBR1 Trip circuit supervision (1)
BitA RegA IEC 61850 name SA name Description Values
LD0.TCSSCBR1
2780 173.12 .CircAlm.stVal ALARM Supervision alarm 1=Alarm
2781 173.13 .mcd
2.3.1.62 LD0.TCSSCBR2 Trip circuit supervision (2)
Table 65: LD0.TCSSCBR2 Trip circuit supervision (2)
BitA RegA IEC 61850 name SA name Description Values
LD0.TCSSCBR2
2782 173.14 .CircAlm.stVal ALARM Supervision alarm 1=Alarm
2783 173.15 .mcd
2.3.1.63 LD0.TR2PTDF1 Stabilized and instantaneous differential protection for
two-winding transformers (1)
Table 66: LD0.TR2PTDF1 Stabilized and instantaneous differential protection for two-winding transformers (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.TR2PTDF1
3000 187.08 .Op.general OPERATE General operate 1=Operate
3001 187.09 .mcd
3002 187.10 .Op.phsA phsA operate 1=Operate
3003 187.11 .mcd
3004 187.12 .Op.phsB phsB operate 1=Operate
3005 187.13 .mcd
3006 187.14 .Op.phsC phsC operate 1=Operate
3007 187.15 .mcd
3008 188.00 .Blk2HSt.general BLKD2H 2nd harmonic res block. 1=Blocking
3009 188.01 .mcd
Section 2 1MRS756878 H
Modbus data mappings
40 RET615
Point List Manual
