ABB RET615 - CTRL.DCSXSWI1 Disconnector Position Indication (1); CTRL.DCSXSWI2 Disconnector Position Indication (2); CTRL.DCSXSWI3 Disconnector Position Indication (3); CTRL.DCXSWI1 Disconnector Control (1)

BitA RegA IEC 61850 name SA name Description Values
2838 177.06 .BlkCls.stVal BLK_CLOSE Close blocked 1=Blocked
2839 177.07 .mcd
2840 177.08 .ItlByPss.stVal ITL_BYPASS Interlock bypass 1=Bypass
2841 177.09 .mcd
2.3.1.6 CTRL.DCSXSWI1 Disconnector position indication (1)
Table 9: CTRL.DCSXSWI1 Disconnector position indication (1)
BitA RegA IEC 61850 name SA name Description Values
CTRL.DCSXSWI1 POSITION
2792 174.08 .Pos.stVal.Close - Close bit 1=Close
2793 174.09 .Pos.stVal.Open - Open bit 1=Open
2794 174.10 .Pos.stVal.Fault - Fault bit 1=Pos(00/11)
2.3.1.7 CTRL.DCSXSWI2 Disconnector position indication (2)
Table 10: CTRL.DCSXSWI2 Disconnector position indication (2)
BitA
RegA IEC 61850 name SA name Description Values
CTRL.DCSXSWI2 POSITION
2795 174.11 .Pos.stVal.Close - Close bit 1=Close
2796 174.12 .Pos.stVal.Open - Open bit 1=Open
2797 174.13 .Pos.stVal.Fault - Fault bit 1=Pos(00/11)
2.3.1.8 CTRL.DCSXSWI3 Disconnector position indication (3)
Table 11: CTRL.DCSXSWI3 Disconnector position indication (3)
BitA
RegA IEC 61850 name SA name Description Values
CTRL.DCSXSWI3 POSITION
2798 174.14 .Pos.stVal.Close - Close bit 1=Close
2799 174.15 .Pos.stVal.Open - Open bit 1=Open
2800 175.00 .Pos.stVal.Fault - Fault bit 1=Pos(00/11)
2.3.1.9 CTRL.DCXSWI1 Disconnector control (1)
Table 12: CTRL.DCXSWI1 Disconnector control (1)
BitA
RegA IEC 61850 name SA name Description Values
CTRL.DCXSWI1 POSITION
3472 217.00 .Pos.stVal.Close - Close bit 1=Close
3473 217.01 .Pos.stVal.Open - Open bit 1=Open
Table continues on next page
1MRS756878 H Section 2
Modbus data mappings
RET615 19
Point List Manual
