ABB RET615 - LD0.MDSOPT1 Runtime Counter for Machines and Devices (1); LD0.MVGAPC1 Move (8 Pcs) (1); LD0.MVGAPC2 Move (8 Pcs) (2)

2.3.1.37 LD0.MDSOPT1 Runtime counter for machines and devices (1)
Table 40: LD0.MDSOPT1 Runtime counter for machines and devices (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.MDSOPT1
2748 171.12 .OpTmWrn.stVal Accum.op.time Warn. 1=Warning
2749 171.13 .mcd
2750 171.14 .OpTmAlm.stVal Accum.op.time Alarm 1=Alarm
2751 171.15 .mcd
2.3.1.38 LD0.MVGAPC1 Move (8 pcs) (1)
Table 41: LD0.MVGAPC1 Move (8 pcs) (1)
BitA RegA IEC 61850 name SA name Description Values
LD0.MVGAPC1
3536 221.00 .SPCSO1.stVal Input 1 0/1=Off/On
3537 221.01 .mcd
3538 221.02 .SPCSO2.stVal Input 2 0/1=Off/On
3539 221.03 .mcd
3540 221.04 .SPCSO3.stVal Input 3 0/1=Off/On
3541 221.05 .mcd
3542 221.06 .SPCSO4.stVal Input 4 0/1=Off/On
3543 221.07 .mcd
3544 221.08 .SPCSO5.stVal Input 5 0/1=Off/On
3545 221.09 .mcd
3546 221.10 .SPCSO6.stVal Input 6 0/1=Off/On
3547 221.11 .mcd
3548 221.12 .SPCSO7.stVal Input 7 0/1=Off/On
3549 221.13 .mcd
3550 221.14 .SPCSO8.stVal Input 8 0/1=Off/On
3551 221.15 .mcd
2.3.1.39 LD0.MVGAPC2 Move (8 pcs) (2)
Table 42: LD0.MVGAPC2 Move (8 pcs) (2)
BitA
RegA IEC 61850 name SA name Description Values
LD0.MVGAPC2
3552 222.00 .SPCSO1.stVal Input 1 0/1=Off/On
3553 222.01 .mcd
3554 222.02 .SPCSO2.stVal Input 2 0/1=Off/On
Table continues on next page
