ABB RET615 - LD0.MAPGAPC3 Multipurpose Protection (3); LD0.MAPGAPC4 Multipurpose Protection (4); LD0.MAPGAPC5 Multipurpose Protection (5); LD0.MAPGAPC6 Multipurpose Protection (6)

2.3.1.33 LD0.MAPGAPC3 Multipurpose protection (3)
Table 36: LD0.MAPGAPC3 Multipurpose protection (3)
BitA
RegA IEC 61850 name SA name Description Values
LD0.MAPGAPC3
3024 189.00 .Op.general OPERATE Stage operate 1 = Operate
3025 189.01 .mcd
3026 189.02 .Str.general START Stage start 1 = Start
3027 189.03 .mcd
2.3.1.34 LD0.MAPGAPC4 Multipurpose protection (4)
Table 37: LD0.MAPGAPC4 Multipurpose protection (4)
BitA RegA IEC 61850 name SA name Description Values
LD0.MAPGAPC4
3028 189.04 .Op.general OPERATE Stage operate 1 = Operate
3029 189.05 .mcd
3030 189.06 .Str.general START Stage start 1 = Start
3031 189.07 .mcd
2.3.1.35 LD0.MAPGAPC5 Multipurpose protection (5)
Table 38: LD0.MAPGAPC5 Multipurpose protection (5)
BitA
RegA IEC 61850 name SA name Description Values
LD0.MAPGAPC5
3036 189.12 .Op.general OPERATE Stage operate 1 = Operate
3037 189.13 .mcd
3038 189.14 .Str.general START Stage start 1 = Start
3039 189.15 .mcd
2.3.1.36 LD0.MAPGAPC6 Multipurpose protection (6)
Table 39: LD0.MAPGAPC6 Multipurpose protection (6)
BitA
RegA IEC 61850 name SA name Description Values
LD0.MAPGAPC6
3012 188.04 .Op.general OPERATE Stage operate 1 = Operate
3013 188.05 .mcd
3014 188.06 .Str.general START Stage start 1 = Start
3015 188.07 .mcd
1MRS756878 H Section 2
Modbus data mappings
RET615 29
Point List Manual
