2.4.1.38 LD0.RESCMMXU1 Residual current measurement (1)
Table 141: LD0.RESCMMXU1 Residual current measurement (1)
RegA
Type Scale IEC 61850 name SA name Description Values
LD0.RESCMMXU1 Residual current (1)
141 u16 1000 .A.res.instCVal.mag I0_INST - amplitude
0.00...40.0
[xIn]
2.4.1.39 LD0.RESCMMXU2 Residual current demand value (2)
Table 142: LD0.RESCMMXU2 Residual current demand value (2)
RegA Type Scale IEC 61850 name SA name Description Values
LD0.RESCMMXU2 Demand value
1965 u16 1000 .AvAmps.mag I_DMD_RES Residual amplitude
0.00..40.0
[xIn]
Update time stamp
1)
1966 u16 - - Year - month
1967 u16 - Day - hour
1968 u16 - Minute - second
1969 u16 - Milliseconds
1970 u16 - - Time quality
1971 u16 1000 .MaxAmps.mag Max demand Io Max Io demand
0.00..40.0
[xIn]
Update time stamp
1)
1972 u16 - Year - month
1973 u16 - Day - hour
1974 u16 - Minute - second
1975 u16 - Milliseconds
1976 u16 - Time quality
1) See the technical manual.
2.4.1.40 LD0.RESCMMXU2 Residual current measurement (2)
Table 143: LD0.RESCMMXU2 Residual current measurement (2)
RegA
Type Scale IEC 61850 name SA name Description Values
LD0.RESCMMXU2 Residual current (2)
155 u16 1000 .A.res.instCVal.mag I0_INST Amplitude
0.00...40.0
[xIn]
1MRS756878 H Section 2
Modbus data mappings
RET615 77
Point List Manual
