2.3.1.57 LD0.SEQSPVC1 Fuse failure supervision (1)
Table 60: LD0.SEQSPVC1 Fuse failure supervision (1)
BitA
RegA IEC 61850 name SA name Description Values
LD0.SEQSPVC1
2996 187.04 .Str.general FUSEF_U Start 1=Start
2997 187.05 .mcd
2998 187.06 .Str3Ph.general FUSEF_3PH 3-phase start 1=Start
2999 187.07 .mcd
2.3.1.58 LD0.SPCGAPC2 Generic control point (16 pcs) (2)
Table 61: LD0.SPCGAPC2 Generic control point (16 pcs) (2)
BitA RegA IEC 61850 name SA name Description Values
LD0.SPCGAPC2
3632 227.00 .SPCS01.stVal Ouput state 1 0/1=Off/On
3633 227.01 .mcd
3634 227.02 .SPCS02.stVal Ouput state 2 0/1=Off/On
3635 227.03 .mcd
3636 227.04 .SPCS03.stVal Ouput state 3 0/1=Off/On
3637 227.05 .mcd
3638 227.06 .SPCS04.stVal Ouput state 4 0/1=Off/On
3639 227.07 .mcd
3640 227.08 .SPCS05.stVal Ouput state 5 0/1=Off/On
3641 227.09 .mcd
3642 227.10 .SPCS06.stVal Ouput state 6 0/1=Off/On
3643 227.11 .mcd
3644 227.12 .SPCS07.stVal Ouput state 7 0/1=Off/On
3645 227.13 .mcd
3646 227.14 .SPCS08.stVal Ouput state 8 0/1=Off/On
3647 227.15 .mcd
3648 228.00 .SPCS09.stVal Ouput state 9 0/1=Off/On
3649 228.01 .mcd
3650 228.02 .SPCS10.stVal Ouput state 10 0/1=Off/On
3651 228.03 .mcd
3652 228.04 .SPCS11.stVal Ouput state 11 0/1=Off/On
3653 228.05 .mcd
3654 228.06 .SPCS12.stVal Ouput state 12 0/1=Off/On
3655 228.07 .mcd
3656 228.08 .SPCS13.stVal Ouput state 13 0/1=Off/On
Table continues on next page
Section 2 1MRS756878 H
Modbus data mappings
38 RET615
Point List Manual
