2.3.1.67 LD0.XAGGIO130 Physical I/O states (AIM card XA130)
Table 70: LD0.XAGGIO130 Physical I/O states (AIM card XA130)
BitA
RegA IEC 61850 name SA name Description Values
LD0.XAGGIO130
3264 204.00 .Ind1.stVal XA130-Input 1 State 0/1=Off/On
3265 204.01 .mcd
.mom-only Mom only alternative
3266 204.02 .Ind2.stVal XA130-Input 2 State 0/1=Off/On
3267 204.03 .mcd
.mom-only Mom only alternative
3268 204.04 .Ind3.stVal XA130-Input 3 State 0/1=Off/On
3269 204.05 .mcd
.mom-only Mom only alternative
3270 204.06 .Ind4.stVal XA130-Input 4 State 0/1=Off/On
3271 204.07 .mcd
.mom-only Mom only alternative
2.3.1.68 LD0.XARGGIO130 Alarm/warning
Table 71: LD0.XARGGIO130 Alarm/warning
BitA
RegA IEC 61850 name SA name Description Values
LD0.XARGGIO130
3032 189.08 .Alm.stVal - XRGGIO130 Alarm 1=Alarm
3033 189.09 .mcd
3034 189.10 .Wrn.stVal - XRGGIO130 Warning 1=Warning
3035 189.11 .mcd
2.3.1.69 LD0.XBGGIO110 Physical I/O states (BIO card XB110)
Table 72: LD0.XBGGIO110 Physical I/O states (BIO card XB110)
BitA
RegA IEC 61850 name SA name Description Values
LD0.XBGGIO110
3216 201.00 .Ind1.stVal X110-Input 1 State 0/1=Off/On
3217 201.01 .mcd
.mom-only Mom only alternative
3218 201.02 .Ind2.stVal X110-Input 2 State 0/1=Off/On
3219 201.03 .mcd
.mom-only Mom only alternative
3220 201.04 .Ind3.stVal X110-Input 3 State 0/1=Off/On
Table continues on next page
Section 2 1MRS756878 H
Modbus data mappings
42 RET615
Point List Manual
