ABB RET615 User Manual

RegA Type Scale IEC 61850 name SA name Description Values
9484 i16 100 .DifANAngVN1.mag. Angle Uo-Io(1) -180.00…
180.00 [deg]
9485 i16 100 .DifAAAngVBC1.mag. Angle UBC-IA(1) -180.00…
180.00 [deg]
9486 i16 100 .DifABAngVCA1.mag Angle UCA-IB(1) -180.00…
180.00 [deg]
9487 i16 100 .DifACAngVAB1.mag Angle UAB-IC(1) -180.00…
180.00 [deg]
9488 i16 100 .DifANAngVN2.mag. Angle Uo-Io(2) -180.00…
180.00 [deg]
9489 i16 100 .DifAAAngVBC2.mag. Angle UBC-IA(2) -180.00…
180.00 [deg]
9490 i16 100 .DifABAngVCA2.mag Angle UCA-IB(2) -180.00…
180.00 [deg]
9491 i16 100 .DifACAngVAB2.mag Angle UAB-IC(2) -180.00…
180.00 [deg]
2.4.1.14 Protection relay's real-time clock (in local time mode) - read and write
(synchronize)
Table 117: Protection relay's real-time clock (in local time mode) - read and write (synchronize)
RegA
Type Scale IEC 61850 name SA name Description Values
9201 Control register 0...2
1)
9202 Year 2000...2999
9203 Month 1...12
9204 Day 1...31
9205 Hour 0...23
9206 Minute 0...59
9207 Second 0...59
9208 Millisecond 0…999
1) See the technical manual.
2.4.1.15 Protection relay's real-time clock (in UTC time mode) - read and write
(synchronize)
Table 118: Protection relay's real-time clock (in UTC time mode) - read and write (synchronize)
RegA
Type Scale IEC 61850 name SA name Description Values
9211 Control register 0...2
1)
9212 Year 2000...2999
9213 Month 1...12
9214 Day 1...31
9215 Hour 0...23
Table continues on next page
1MRS756878 H Section 2
Modbus data mappings
RET615 65
Point List Manual

ABB RET615 Specifications

General

Rated Frequency	50/60 Hz
Weight	Approx. 2.5 kg
Type	Protection Relay
Communication Protocols	IEC 61850, Modbus, DNP3
Protection Functions	Overcurrent, Earth fault, Thermal overload, Frequency
Input Voltage	24-250 V DC
